TriMark RV Door Lock, Keyless Option, 23738-01

Description

TriMark Model 030-1400 Right Hand RV Door Lock 23738-01

Two point lock arm

030-1400,RH,LGB,KOP,1PT,LGS

Features/Benefits

• Offers updated styling
• Inside lock provides override if outside paddle should be locked
• Molded rubber gasket for flange of housing provides resistance to water and dust infiltration

Finish

• Standard black powder coated
• Also available in buffed copper-nickel-nickel-chrome plated or combination black powder coated housing and buffed chrome paddle

Material

• Sturdy zinc die cast alloy housing and paddle
• Steel components: Zinc plated, mild steel

Installation

• Handle is easy to install with supplied single 1/4-20 UNC nut and mounting bracket (mounting torque not to exceed 30 in-lbs (3.39 N-m)
• Either handed version can be installed in a wide range of locations in both horizontal or vertical orientations (left hand shown)
• Retrofits with most 030-0400 flush paddle handles
